MODEL FEATURES

The TF33.7 115 is equipped with the Deutz 115hp engine in conjunction with the 40km/h Eco Power Drive (EPD) hydrostatic transmission that automatically control and adjust the engine revolutions based on operating conditions. As a result, the engine speed is disconnected from the accelerator pedal. This technology achieves a reduction in fuel consumption of 18%.

The 115 model is equipped with the EPD TOP version which offers “Speed Control” mode: the system memorises the machine’s movement speed and keeps it constant, ideal for yard handling operations; it also includes the engine speed management function directly from the joystick.

The 115 model includes a Reversible Fan, Pick up Hitch, Trailer braking and Tractor Type Approval ideal for towing trailers for all Agricultural requirements.

The strength of the Turbofarmer range lies in its wide range of products, which allows you to choose between numerous versions with exclusive technological contents, like the BSS (Boom Suspension System) available as an option, which works with pneumatic dampers that significantly reduce shocks while travelling at high speed or on rough terrain.

Engine: Deutz 3.6 85kW/115Hp
Transmission: Hydrostatic
Hydraulic system: Load Sensing + Flow Sharing 125 l/m 210 Bar
Electronic Joystick
CDC: light Dynamic Load Control

• Lift Capacity 3300kg
• Lift height 6.6 metres
• EPD Top "Speed Control" & Maximum speed of 40km/h
• Auto revving joystick



View Merlo TF33.7 115 Brochure

---

ATTACHMENTS

The widest range of attachments on the market, designed and developed by Merlo. This ensures the reliability and maximises the performance and comfort of the telehandlers produced by Merlo. The purpose is to make your work easier and more productive, with advanced technical solutions and a never ending research. For this Merlo is also able to produce special attachments for the most demanding customers. To make the most of Merlo telehandlers in every field, various ranges of equipment dedicated to different applications, we have selected the top most preferred attachments.

Please download their latest attachment brochure below to see the full range.

View Construction Attachment Brochure  View Agricultural Attachment Brochure
