Lifting Performance
High-tier performance in a sub-2m chassis, offering industrial-grade stability.
- Max Capacity: 2,700kg
- Max Height: 5.9m (1,800kg at peak)
- Max Reach: 3.3m (1,000kg at tip)
- Boom Design: Single piece with integrated hydraulic lines.
The Merlo Cab
Merlo compacts feature the same modular cab as their 12-tonne machines, ensuring no compromise on comfort.
- Width: 1,010mm (Largest in class).
- Visibility: 360° unobstructed view with 4.3m² of glass.
- Ergonomics: Fully adjustable seat and electronic joystick.
- Protection: ROPS and FOPS Level II certified.
Advanced Features
Includes patented Merlo technologies for efficiency and easier operation on site.
- EPD System: Eco Power Drive reduces fuel consumption by up to 18%.
- Portal Axles: Higher ground clearance for rough terrain while keeping center of gravity low.
- Three Steering Modes: Front-wheel, 4-wheel, and Crab steer.
- Z-Kinematics: High breakout force for bucket work.
Technical Specs
Power delivery via a maintenance-friendly Kohler Tier 5 engine.
- Engine: 75hp (55.4kW) High Torque.
- Hydraulics: 95 L/min @ 210 Bar.
- Chassis: "Integral" ring design for maximum strength.
- Speed: 40km/h high-speed travel.
Shipping & Support
Professional Isle of Wight delivery service with expert technical setup.
- Status: In Stock & Ready.
- Delivery: Free across the Island.
- PDI: Comprehensive expert setup.
