New Kubota KX085-5 2PGL 2-Piece Boom Midi
Excavator
Unmatched Articulation, Maximum Lift Power & Multi-Tasking
Versatility. The Kubota KX085-5 2PGL is the ultimate urban development
and civil engineering specialist. Standardized on a solid **fixed
undercarriage** with protective **450 mm Rubber Tracks**, its defining feature
is a hydraulic **2-Piece Articulated Boom**. This advanced mechanism lets
operators adjust the boom angle on the fly, allowing the machine to work in
incredibly tight spaces, dig vertically directly alongside the tracks, and
comfortably lift heavy loads closer to the chassis. Inside the premium
**Air-Conditioned Cabin**, operators enjoy quiet, climate-controlled comfort
and direct joystick control over high-flow dual auxiliary hydraulic systems
(AUX1 & AUX2). With an extended **Long Arm** for superb depth, and dual
**Amber & Green Safety Beacons** pre-installed, this 2PGL configuration
delivers premium utility for highway works, narrow trenches, and congested
jobsites.
Articulated 2-Piece Boom
- Extreme Versatility: Adjust the boom geometry to clear
overhead obstacles or dig directly underneath the machine cab.
- Superior Lift Capacity: Retracting the middle
articulation brings loads closer to the machine, boosting lifting
stability.
- Extended Working Range: Expands the maximum dumping
height and reach envelope compared to traditional mono-booms.
- Ideal for Narrow Sites: Perfectly designed for highway
utility work, single-lane closures, and urban construction.
Request a Quote
Luxury Air-Conditioned Cab
- High-Capacity Climate Control: Maintain an optimal
workspace climate regardless of external summer heat or dust storms.
- Spacious Workspace: Industry-leading operator legroom,
adjustable armrests, and a luxury pneumatic air-suspension seat.
- Clear Vision Styling: Expansive glass glazing paired with
slim cab pillars provides unmatched visibility to the attachment.
- Intelligent LCD Display: 7-inch color monitor provides
quick, clear access to engine vitals and customizable flow
settings.
Advanced Jobsite Safety
- Amber Hazard Beacon: Roof-mounted high-intensity LED
strobe alerts colleagues of ongoing machinery operation.
- Green Safety Indicator: Lights up externally to verify
that the operator’s seatbelt is fully buckled.
- Civil Site Compliant: Hassle-free site induction on major
civil engineering and highway agency projects.
- Protected Wiring: Factory-routed harness runs safely
through the chassis to prevent snagging during close-quarters
work.
Surface-Safe Rubber Tracks
- 450mm Quality Rubber Tracks: Outstanding tractive force
without scarring tarmac, pavements, or concrete kerbs.
- Robust Long Arm: Specially matched to the 2-piece boom to
provide an optimal blend of cycle speed and maximum outreach.
- Anti-Theft Immobilizer: Secured by Kubota's electronic
coded key anti-theft ignition system.
- Fixed Undercarriage Frame: Heavy-duty, low-maintenance
rigid track frame keeps the center of gravity stable.
Technical Specifications - Kubota KX085-5
2PGL (2-Piece Boom Elite)
| SPECIFICATION |
DETAILS |
| Operating Weight |
8,912 kg |
| Engine Model |
Kubota V3307-CR-TE5 (Stage V Common Rail with DPF & DOC) |
| Engine Output |
49.0 kW / 66.6 PS @ 2000 rpm |
| Boom Type |
Hydraulic 2-Piece Articulated Boom System |
| Cabin Comfort |
Factory Air-Conditioning & Premium Air-Suspension Seat |
| Track Configuration |
450 mm High-Performance Rubber Tracks |
| Arm Configuration |
Extended Long Arm Edition |
| Auxiliary Hydraulic Lines |
AUX 1 (High Flow) & AUX 2 (Secondary Proportional) |
| Max. Digging Depth |
4,560 mm |
| Max. Digging Reach |
7,560 mm |
| Max. Dumping Height |
5,740 mm |
| Fuel Tank Capacity |
115 Litres |
| On-Board Safety Kit |
Factory Dual Beacon Kit (Amber Warning & Green Belt) |
| Bucket Breakout Force |
54.6 kN (5,570 kgf) |
