AUSA D151AEG

Electric power for the whole day.

The D151AEG dumper was designed to offer capacity for a full working day without needing to be recharged.

With the machine’s integrated charging cable, you can connect directly to the mains via a 110 V, 230 V or 415 V socket with a fast charger.

Thanks to its minimal noise emissions, it can be used in more applications than a traditional dumper, as well as in works to be carried out at night. Also, the permanent 4WD gives it a lot of power, so it can tackle the most difficult terrain.

Technical data

General

Unloading system - Rotating
Load capacity - 1500 Kg
Chassis - Articulated
Water skip capacity - 520 l
Level skip capacity - 626 l
Heaped skip capacity - 900 l
Empty weight - 1530 Kg
Transmission - Electric
Reversibility - Non-reversible

Battery

Battery type - Lithium-Ion Battery (NCM)
Gross capacity - 9.3 kWh
System voltage - 48 V
Range -

May vary according to weather conditions and use. For temperatures below 0ºC, it is recommended to include the Additional battery for longer range (+3.1 kWh)

One intense shift.

Charge

Charger - Integrated
Charging time - 20-80%

May vary according to weather conditions and the type and power of the charging point 2 h (230V))

Charging time - 20-80% (fast charger)

May vary according to weather conditions and the type and power of the charging point 1 h (415V)

Charging cable - plug type 110V (yellow); 230V (blue); 415V (red).

Engine

Peak power - 17.3 kW
Nominal power - 7.6 kW
Torque - 130
Emissions Zero - emission

Driving

Max. speed - 14 Km/h
Maximum gradient - 34%
External turning radius - 3390 mm
Traction - 4x4
Tyres 10.0/75-15.3.

Hydraulic system

Hydraulic circuit -12 cc gear pumps
Flow rate - 26.4 l/min
Working pressure - 180 bar.

Tank capacity

Hydraulic system - 24.5 l.

Brakes

Service - Hydraulic
Parking - Negative.

---

---

Key: fitted as standard  otherwise optional

Driving position
Rear folding ROPS protective structure

Safety
Seat belt with fasten sensor
Seat with operator's presence sensor
LED rotating beacon
Green rotating beacon
Acoustic warning for reverse gear
Emergency stop
Anti-vandal security system
Hill Holder - hill-start assist
Negative brake

Lighting and driving

Road lights
Front LED working lights
Rear-view mirror

Comfort
Adjustable ergonomic seat
All-in-one joystick

Advanced equipment
Electric transmission
Digital display
Advanced support
AUSAnow fleet manager
Additional battery for longer range (+3.1 kWh)

Accessories
Metal engine cover
Front mudguards
Waterproof document holder
Biodegradable hydraulic oil
Towing ball and pintle hitch
Power socket for the trailer

Parts
1,000 h maintenance kit
Standard spare wheel Standard Optional
